NAX 2530Z IKO


Country Of Origin: JAPAN
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - IKO
Item Number - NAX 2530Z IKO
Also Known As - NAX2530Z
Category - Needle Roller Bearings with Thrust Ball Bearing without Inner Ring
Shaft Diameter (mm) - 25
Boundary Dimension (Fw) mm - 25
Boundary Dimension (D) mm - 37
Boundary Dimension (D1) mm - 42
Boundary Dimension (D2) mm - 43
Boundary Dimension (L) mm - 30
Boundary Dimension (H) mm - 11
Boundary Dimension (l1) mm - 9.5
Minimum Boundary Dimension (rs) mm - 0.6
Boundary Dimension (di) mm - 25
Minimum Standard Mounting Dimension (da) mm - 35
Basic Radial dynamic load rating (C) N - 20000
Basic Axial dynamic load rating (C) N - 19600
Basic Radial Static load rating (C0) N - 32100
Basic Axial Static load rating (C0) N - 29700
Allowable Rotational Speed (min-1) - 7000
Weight (kg) - 0.135
Needle Roller Bearing without Dust Cover - NAX 2530

** Images are for representation purposes only
