Description
Brand - ZEN
Item Number - NATR35-PPX ZEN
Category - Yoke Type Track Rollers (NATR and NATV)
Inner Diameter (d) mm - 35
Outer Diameter (D) mm - 72
Width (B) mm - 29
C (mm) - 28
d2 (mm) - 58
r (mm) - 1.1
Weight (kg) - 0.547
Dynamic Load Rating (N) - 25000
Static Load Rating (N) - 44000
Limiting Speed - 1000
Fatigue Limit Load - 5300
Radial Play - 0.010-0.030
Outer Ring Material - AISI51200
Inner Ring Material - AISI51200
Ball Material - AISI51200
** Images are for representation purposes only
