Description
Brand - IKO
Item Number - NART 10 FR IKO
Also Known As - NART10FR
Category - Non-Separable Roller Followers (Stainless Steel Made) With Cage/With Inner Ring
Type - Shield Type
Shaft Diameter (mm) - 10
Bore Diameter (d) mm - 10
Outer Diameter (D) mm - 30
Width (B) mm - 15
Boundary dimension (C) mm - 14
Boundary dimension (a) mm - 22.5
Basic Dynamic Load Rating (C) N - 6330
Basic Static Load Rating (C0) N - 7830
Maximum allowable static load (N) - 7830
Sealed Type Bearing - NART 10 FUUR
Weight (kg) - 0.061
Suffix Description :
F - Stainless Steel
R - With Crowned Outer Ring
** Images are for representation purposes only
