NA 4918UU IKO


Country Of Origin: JAPAN
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - IKO
Item Number - NA 4918UU IKO
Also Known As - NA4918UU
Category - Machined Type Needle Roller Bearing with Seal with Inner Ring
Seal - Two Seals
Shaft Diameter (mm) - 90
Bore Diameter (d) mm - 90
Outer Diameter (D) mm - 125
Boundary Dimension (C) mm - 35
Boundary Dimension (B) mm - 36
Minimum Boundary Dimension (rs) mm - 1.1
Boundary Dimension (Fw) mm - 105
Miniimum Standard Mounting Dimension (da) mm - 96.5
Maximum Standard Mounting Dimension (da) mm - 103
Maximum Standard Mounting Dimension (Da) mm - 118.5
Basic Dynamic Load Rating (C) N - 106000
Basic Static Load Rating (C0) N - 238000
Allowable Rotational Speed (min-1) - 1800
Assembled Inner Ring - LRTZ 9010536
Weight (kg) - 1.36
Bearing with One Seal - NA 4918U

** Images are for representation purposes only
