NA 2060 NADELLA

Brand - NADELLA
Item Number - NA 2060 NADELLA
Category - Full Complement Needle Bearing with Inner Ring

Principal Dimensions & Load Ratings (Metric) :
Shaft Diameter - 60 mm
Inner Diameter (d) - 60 mm
Outer Diameter (D) - 90 mm
Width (B) - 28 mm
Dimension (Fw) - 72.6 mm
Minimum Chamfer Dimension (rs) - 0.85 mm
Dynamic Load Rating (C) - 72 kN
Static Load Rating (C0) - 165 kN
Speed Rating with Oil - 5200 rpm
Speed Rating with Grease - 3400 rpm
Weight - 0.413 kg

Description of Prefix :
NA - Full complement needle bearings with inner ring

♦ ♦ Images are for representation purposes only
