Description
Brand - Link-Belt
Item Number - MU1308DX Link-Belt
Also known as - NF308
Category - Cylindrical Roller Bearing Single Row
Inner (d) MM - 40
Outer (D) MM - 90
Width (B) MM - 23
Inner (d) Inch - 1.5748
Outer (D) Inch - 3.5433
Width (B) Inch - 0.9055
Weight (kg) - 0.671
Bore - C - Cylindrical Bore
Seal - No Seal
Cage Type - FC - Full Complement, No Cage
External Modification - No External Modification
Radial Internal Play - Cn Normal Internal Play
Precision - Standard Precision
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
