Description
|
Technical Data |
|
| Power (P) | 3.5 kW |
| MF Frequency Range | 10 – 50 kHz |
| Voltage (U) | 230 V |
| Current Type | AC power |
| Amperage (I) | 16 A |
| Power Frequency (F) | 50 – 60 Hz |
| Dimensions Display | 4.3 inch |
| Dimensions of Generator [LxWxH] (mm) | 320 x 350 x 150 |
| Weight (m) | 7.85 kg |
|
Functions |
|
| Forced air cooling | + |
| Temperature Measurement |
For Type K Thermocouple
|
| Accuracy | ± 3.5 °C / ± 6.3 °F |
| Inductor Recognition | — |
| Temperature Sensor |
Yes, for max 300 °C / 572 °F
|
| Extra Thermocouple Input | + |
| Heat Curve in Display | + |
| Setpoint Temperature | Via Touchscreen |
| Setpoint Temperature Curve | + |
| Setpoint Timer | Via Touchscreen |
| Selection Operating Mode | Via Touchscreen |
| Digital Readings Temperature |
Setpoint and actual value on touchscreen
|
| Digital Readings Time |
Setpoint and actual value on touchscreen
|
| USB Connection | + |
| Heating log | + |
|
Additional Information |
|
| Installation in Operational State: LED on Front | Signaling by ... |
| Error Message: Acoustic Signal | Signaling by ... |
| End of Heating Cycle: Acoustic Signal | Signaling by ... |
