MBH8090-SS RBC

Brand - RBC
Item Number - MBH8090-SS RBC
Category - High Misalignment Spherical Plain Bearings
Basic Part Number - (-8090)

Principal Dimensions & Load Ratings (Metric) :
Nominal Inside Diameter (d) - 80 (-0.015) mm
Nominal Outside Diameter (D) - 130 (-0.018) mm
Nominal Inner Ring Width (B) - 75 (-0.15) mm
Nominal Outer Ring Width (C) - 50 (-0.50) mm
Sphere Diameter (K) - 117 mm
Unmounted Diametral Clearance - 0.13/0.23 mm
Shaft Shoulder Diameter (d1) - 90 mm
Tilt Angle (α) - 9°
Maximum Shaft Fillet (r1) - 1 mm
Maximum Housing Fillet (r2) - 1 mm
Approximate Weight - 3.72 kg
Static Radial Load Limit - 2520 kN
Static Thrust Load Limit - 422 kN
Static Dynamic Load Limit - 500 kN
Maximum Recommended Shaft Diameter ISO f6 (Slip Fit) - 79.97 mm
Minimum Recommended Shaft Diameter ISO f6 (Slip Fit) - 79.951 mm
Maximum Recommended Shaft Diameter ISO m5 (Press Fit) - 80.024 mm
Minimum Recommended Shaft Diameter ISO m5 (Press Fit) - 80.011 mm
Maximum Recommended Housing Bore ISO R7 (Press Fit) - 129.952 mm
Minimum Recommended Housing Bore ISO R7 (Press Fit) - 129.912 mm

Notes about MBH Series :
Thanks to a thicker inner ring, the BH-L and MBH series can accommodate increased misalignment. These bearings are offered in both open and sealed versions, with options in inch and metric sizes.

Other salient points to be noted :
• All dimensions apply before MoS2 coating and Fracture.

♦ ♦ Images are for representation purposes only
