LUBM 030 NADELLA

Brand - NADELLA
Item Number - LUBM 030 NADELLA
Category - Lubricator

Principal Dimensions & Load Ratings (Metric):
Dimension (A) - 9.5 mm
Dimension (B) - 16 mm
Dimension (U) - 8 mm
Dimension (E) - 30 mm
Dimension (T) - 15 mm
Dimension (H) - 6.5 mm
Dimension (C) - 20.5 mm
Dimension (G*) - M2.5
Dimension (S) - 9 mm
Dimension for C3 RCL (L) - 83 mm
Dimension for C4 RCL (L) - 103 mm
Recommended Pairings - LM 30

Description of Prefix:
LUBM - Lubricator for U-Line system (carriages running in LM rails)

Other salient points to be noted:
* One lubricator for packaging. Countersunk head screws for the mounting are already in the packaging

• The lubricator is supplied with the felt already lubricated. The lubricant has a mineral oil base
• The lubricator can be mounted on carriages RCL, RAL and RYL

Optional Features:
• Felt without lubricant (D)
