Description
Brand - ZEN
Item Number - LR208-NPP ZEN
Category - LR Series (Track Rollers)
Inner Ring Dimension (d) mm - 40
Outer Ring Dimension (D) mm - 85
Width (B) mm - 18
Radius (rs) mm - 1.1
Dynamic Load Rating (N) - 22800
Static Load Rating (N) - 13600
Limiting Speed (NPP and NPPU) - 4
Weight (kg) - 0.45
Radial Play - 0.006-0.02
Outer Ring Material - AISI52100
Inner Ring Material - AISI52100
Ball Material - AISI52100
** Images are for representation purposes only
