Description
Brand - ZEN
Item Number - LFR5201-NPP ZEN
Category - LR Series (Track Rollers)
Inner Ring Dimension (d) mm - 12
Outer Ring Dimension (D) mm - 35
Width (B) mm - 15.9
Radius (rs) mm - 0.5
Dynamic Load Rating (N) - 8600
Static Load Rating (N) - 5100
Limiting Speed (NPP and NPPU) - 7
Limiting Speed (KDD and KDDU) - 10
Weight (kg) - 0.064
-
Outer Ring Material - AISI52100
Inner Ring Material - AISI52100
Ball Material - AISI52100
** Images are for representation purposes only
