Description
Brand - FAG
Item Number - L10VA800T FAG
Also known as - CSCF080 FPCF800 KF080CP0 KF080CPO NBC20319
Category - Deep Groove Ball Bearings Single Row
Inner (d) MM - 203.2
Outer (D) MM - 241.3
Width (B) MM - 19.05
Inner (d) Inch - 8
Outer (D) Inch - 9.5
Width (B) Inch - 0.75
Weight (kg) - 1.46
Bore - C - Cylindrical Bore
Seal - No Seal
Cage Type - P - Plastic Molded Cage
External Modification - No External Modification
Radial Internal Play - Cn Normal Internal Play
Precision - ABEC.1 Tolerances
Lubrication - Standard Lubrication
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
Special Treatment - No Special Treatment
