Description
Brand - TIMKEN
Item Number - K20907 TIMKEN
Category - Cup Shims
Thickness (mm) - 0.18
Thickness (inch) - 0.007
Cap Screw Number - 4
Cap Screw Size (mm) - 9.7
Cap Screw Size (inch) - 0.38
D1 (mm) - 59.4
D1 (inch) - 2.34
D2 (mm) - 76.2
D2 (inch) - 3
D3 (mm) - 10.4
D3 (inch) - 0.41
ra (mm) - 9.7
ra (inch) - 0.38
rb (mm) - 4.8
rb (inch) - 0.19
** Images are for representation purposes only
