IRT 5030 IKO


Country Of Origin: JAPAN
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - IKO
Item Number - IRT 5030 IKO
Category - Inner Ring for Shell Type Needle Roller Bearing
Shaft Diameter (mm) - 50
Boundary Dimension (d) mm - 50
Boundary Dimension (F) mm - 60
Boundary Dimension (B) mm - 30.5
Minimum Boundary Dimension (rs) mm - 1.5
Minimum Standard Mounting Dimension (da) mm - 58
Maximum Standard Mounting Dimension (da) mm - 59
Weight (kg) - 0.205
Probable Assembled Bearings - TA 6030Z

** Images are for representation purposes only
