Description
Brand - IKO
Item Number - IRT 2220 IKO
Category - Inner Ring for Shell Type Needle Roller Bearing
Shaft Diameter (mm) - 22
Boundary Dimension (d) mm - 22
Boundary Dimension (F) mm - 26
Boundary Dimension (B) mm - 20.5
Minimum Boundary Dimension (rs) mm - 0.3
Minimum Standard Mounting Dimension (da) mm - 24
Maximum Standard Mounting Dimension (da) mm - 25
Weight (kg) - 0.024
Probable Assembled Bearings - TA 2620Z, YT 2620
** Images are for representation purposes only
