IRT 1515-2 IKO


Country Of Origin: JAPAN
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - IKO
Item Number - IRT 1515-2 IKO
Category - Inner Ring for Shell Type Needle Roller Bearing
Shaft Diameter (mm) - 15
Boundary Dimension (d) mm - 15
Boundary Dimension (F) mm - 20
Boundary Dimension (B) mm - 15.5
Minimum Boundary Dimension (rs) mm - 0.3
Minimum Standard Mounting Dimension (da) mm - 17
Maximum Standard Mounting Dimension (da) mm - 19
Weight (kg) - 0.0164
Probable Assembled Bearings - TA 2015Z, YT 2015

** Images are for representation purposes only
