Description
|
Technical Data |
|
| Voltage (U) | 400 V |
| Current Type | Three-phase AC |
| Power Frequency (f) | 50 – 60 Hz |
| Max. Working Stroke Main Cylinder (scm max) | 330 mm |
| Max. Operating Pressure (pmax) | 700 bar |
| Grip width, min. (wmin) | 300 mm |
| Grip width, max. (wmax) | 1,650 mm |
| Grip depth, max. (tmax) | 1,175 mm |
| Pulling force (FP) | 1,470 kN |
| Working height range [bottom – center axis cylinder] (mm) | 830 – 1330 |
| Dimensions [LxWxH] (mm) |
2990 x 1030 x 1390
|
| Weight (m) | 1,200 kg |
|
Functions |
|
| Functional principle |
Electrically Operated Hydraulic Unit For Main Cylinder, Height Adjustment as Well as Opening and Closing of the Gripper Arms, Safety Valve Prevents Overloading
|
| Castors |
2 Swivel Castors with Brake Function, 2 Fixed Castors
|
| Included In Delivery |
Remote Control, 7 Adapter Pieces (Total Length 1125 mm), Security Blanket
|
** BETEX is a registered trademark of Bega International BV, Netherlands, which is a Schaeffler Company since August 2021.
**We are Authorised Distributors of Schaeffler, since 1977.
