Description
Brand - ZEN
Item Number - HK1416 ZEN
Category - Needle Roller Bearing
Inner Ring Dimension (d) mm - 14
Outer Ring Dimension (D) mm - 20
Width (B) mm - 16
Dynamic Load Rating (N) - 7100
Static Load Rating (N) - 8500
Limiting Speed - 10500
Weight (kg) - 0.013
Outer Ring Material - ST14 (Nr. 1.0338)
Inner Ring Material - ST14 (Nr. 1.0338)
Ball Material - AISI52100
** Images are for representation purposes only
