HCB71922-CDLR-T-P4S FAG

SANTENT.IN

Download Data Sheet

Country Of Origin: Imported

Variant

Share this product

Brand - FAG
Item Number - HCB71922-CDLR-T-P4S FAG
Category - Spindle Bearing
Weight (m) kg - 0.69
Inner Diameter (d) mm - 110
Outer Diameter (D) mm - 150
Width (B) mm - 20
Minimum Chamfer Dimension (rmin) mm - 1.1
Minimum Chamfer Dimension (r1min) mm - 1.1
Distance Ring Grooves (BN) mm - 4
Distance to Lubrication Hole (SN) mm - 12
Width of Lubricating Groove (SB) mm - 2.2
Contact angle (°) - 15
Diameter Shaft Shoulder Clearance - h12
Diameter Shaft Shoulder (da) mm - 117
Shoulder Diameter Outer Ring Clearance - H12
Shoulder Diameter Outer Ring (Da) mm - 143
Basic Dynamic Load Rating, Radial (Cr) N - 61000
Basic Static Load Rating, Radial (C0r) N - 45000
Limiting Speed for Grease Lubrication (nG grease) min⁻¹ - 12000
Limiting Speed for Oil Lubrication (nG oil) min⁻¹ - 19000
Preload Force Light (FV L) N - 158
Preload Force Medium (FV M) N - 570
Preload Force Heavy (FV H) N - 1199
Lift-off Force Light (KaE L) N - 468
Lift-off Force Medium (KaE M) N - 1777
Lift-off Force Heavy (KaE H) N - 3931
Axial Rigidity Light (Ca L) N/µm - 82.1
Axial Rigidity Medium (Ca M) N/µm - 138
Axial Rigidity Heavy (Ca H) N/µm - 193
