GE 20EC IKO

IKO

Download Data Sheet

Country Of Origin: JAPAN

Variant

Share this product

Brand - IKO
Item Number - GE 20EC IKO
Also Known As - GE20EC
Category - Maintenance-Free Spherical Bushings
Shaft Diameter (mm) - 20
Bore Diameter (d) mm - 20
Outer Diameter (D) mm - 35
Width (B) mm - 16
Boundary Dimension (C) mm - 12
Boundary Dimension (dk) mm - 29
Minimum Boundary Dimension (rs) mm - 0.3
Minimum Boundary Dimension (r2s) mm - 0.3
Permissible Tilting Angle Degree (α) - 9
Minimum Mounting Dimension (da) mm - 22.5
Maximum Mounting Dimension (da) mm - 24
Maximum Mounting Dimension (Da) mm - 32.5
Minimum Mounting Dimension (Da) mm - 28
Dynamic Load Capacity (Cd) N - 34100
Static Load Capacity (Cs) N - 85300
Weight (kg) - 0.065

** Images are for representation purposes only
