Description
Brand - NADELLA
Item Number - GCL14 NADELLA
Category - Cam Followers with Stud
Principal Dimensions & Load Ratings (Metric) :
Outer Diameter (D) - 14 mm
Hole Diameter (d1) * - 6 mm
Dimension (L) - 26 mm
Dimension (B1) - 10 mm
Dimension (B2) - 16 mm
Threading (G) - M6x1
Dimension (G1) - 8 mm
Dimension (C) - 9 mm
Dimension (C1) - 0.25 mm
Dimension (dA) - 11.8 mm
Dimension (r) - 0.3 mm
Dimension (P) - 6.4 mm
Load Coefficients (Cw) - 3400 N
Dynamic Load Coefficients (Fr) - 1500 N
Static Load Coefficients (For) - 2800 N
Speed Limit with Grease - 5500 RPM
Weight - 0.016 kg
Clamping Torque - 3 Nm
Description of Prefix:
GCL - Concentric Cam Follower with Stud with Cylindrical Outer Ring
Other salient points to be noted:
* Hole diameter for assembly d1 H7
• The concentric cam followers with stud in the GC Mini series are supplied with two clamping nuts
♦♦ Images are for representation purposes only
