Description
Brand - INA
Item Number - G5206-2RS-N INA
Category - Angular Contact Ball Bearing Double Row
Also known as - 8873660000
Inner (d) MM - 30
Outer (D) MM - 62
Inner (d) Inch - 1.1811
Outer (D) Inch - 2.4409
Weight (kg) - 0.4
Bore - C - Cylindrical Bore
Seal - 2RS - Rubber Seal on Two Sides
Cage Type - S - Steel or Standard Cage
External Modification - N - Snap Ring Groove in Outer Ring
Radial Internal Play - Cn Normal Internal Play
Precision - Standard Precision
Lubrication - Standard Lubrication
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring - Standard
** Images are for representation purposes only
