Description
Brand - INA
Item Number - FLCTE5/8 INA
Category - Flanged Housing Unit
Also known as - (RAE5/8NPPB+LCTE03)
Inner (d) MM - 15.88
Outer (D) MM - 81
Width (B) MM - 30.5
Inner (d) Inch - 0.625
Outer (D) Inch - 3.189
Width (B) Inch - 1.2008
Weight (kg) - 0.3
Seal - 2F - Standard Seal for Y-bearings
Lubrication - Standard Lubrication
Special Treatment - No Special Treatment
** Images are for representation purposes only
