Description
Brand - FAG
Item Number - F-802023.TR4 FAG
Category - Four-Row Tapered Roller Bearing
Weight (Kg) - 137
Inner Diameter (d) mm - 355.6
Outer Diameter (D) mm - 482.6
Outer Width (T) mm - 269.875
Inner Width (B) mm - 265.112
Basic Dynamic Load Rating (Cr) kN - 3150
Basic Static Load Rating (C0r) kN - 6400
Dynamic Axial Load Factor (Y1) - 1.36
Dynamic Axial Load Factor (Y2) - 2.03
Static Axial Load Factor (Y0) - 1.33
Fatigue Limit Load (Cur) kN - 620
