Description
Brand - FAG
Item Number - F-801094.TR1-H144 FAG
Category - Tapered Roller Bearing Single Row (Standard)
Weight (m) kg - 3.55
Inner Diameter (d) mm - 196.85
Outer Diameter (D) mm - 254
Inner Ring Width (B) mm - 27.783
Outer Ring Width (C) mm - 21.433
Total Width (T) mm - 28.575
Basic Dynamic Load Rating (C) N - 201000
Basic Static Load Rating (C0) N - 400000
Limiting Speed (n) min–1 - 2700
