Description
Brand - INA
Item Number - F-611798.ZKLFA-SPEC GREASE
INA
Category - Angular Contact Ball Bearing Double Row
Also known as - 852419380000
| manufacturer | INA |
| dimensions | 30 x 73.4 x 38 |
| Weight | 1.11 kg |
| D1 - flange diameter [mm] | 98 |
| split ring | inner |
| e - flange thickness [mm] | 12.7 |
| type | double row angular-contact ball bearing |
| sealing | double-sided rubber, contact |
| contact angle [°] | 60 |
| cage | polyamide |
Bore - C - Cylindrical Bore
Seal - 2RS - Rubber Seal on Two Sides
Cage Type - S - Steel or Standard Cage
External Modification - No External Modification
Radial Internal Play - Cn Normal Internal Play
Precision - Standard Precision
Lubrication - Standard Lubrication
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring - Split inner ring
** Images are for representation purposes only
