Description
Brand - FAG
Item Number - F-574387 FAG
Category - Axial Deep Groove Ball Bearing
Inner Diameter (d) mm - 600
Outer Diameter (D) mm - 705
Height (T) mm - 85
Minimum Mounting Dimension (D1) mm - 600
Dimension (d1) mm - 705
Chamfer Dimension (r) mm - 3
Minimum Mounting Dimension (da) mm - 672
Maximum Mounting Dimension (Da) mm - 633
Mounting Dimension (ra) mm - 3
Basic Dynamic Load Rating (C) kN - 640
Basic Static Load Rating (C0) kN - 4400
Limiting Speed for Oil Lubrication (nG oil) 1/min - 450
Axial Run-Out (µm) - 5
Minimum Load Factor (A) - 101
** Images are for representation purposes only
