Description
Brand - ZEN
Item Number - CS203 ZEN
Category - Steel Inserts (CS200)
Alternative Part Number (Cross Reference) - 1726203-2RS
Inner Diameter (d) mm - 17
D2 (mm) - 40
Width (B) mm - 12
Minimum r (mm) - 0.6
Dynamic Load Rating (N) - 9580
Static Load Rating (N) - 4780
Limiting Speed - 12500
Weight (kg) - 0.065
Outer Ring Material - AISI52100
Inner Ring Material - AISI52100
Ball Material - AISI52100
** Images are for representation purposes only
