CRH 64 VBUU IKO

IKO

Download Data Sheet

Country Of Origin: JAPAN

Variant

Share this product

Brand - IKO
Category - Inch Series Heavy Duty Cam Followers (Full Complement Type / Stud Head Hex Hole)
Item Number - CRH 64 VBUU IKO
Also Known As - CRH64VBUU
Type - Sealed Type with Cylindrical Outer Ring
Shield Type - CRH 64 VB
Stud Diameter (mm) - 50.8
Stud Diameter (inch) - 2
Weight (kg) - 4.96
Outside Diameter of Outer Diameter (D) mm - 101.6
Outside Diameter of Outer Diameter (D) inch - 4
Width of Outer Ring (C) mm - 57.15
Width of Outer Ring (C) inch - 2.25
Boundary Dimension (d1) mm - 50.8
Boundary Dimension (d1) inch - 2
G - 2 - 12 UN
Boundary Dimension (G1) mm - 38.1
Boundary Dimension (G1) inch - 1.5
Maximum Boundary Dimension (B) mm - 59.4
Maximum Boundary Dimension (B) inch - 2.34
Boundary Dimension (B2) mm - 88.9
Boundary Dimension (B2) inch - 3.5
Boundary Dimension (B3) mm - 19.05
Boundary Dimension (B3) inch - 0.75
Boundary Dimension (C1) mm - 1.588
Boundary Dimension (C1) inch - 0.0625
Boundary Dimension (g1) mm - 6.35
Boundary Dimension (g1) inch - 0.25
Boundary Dimension (g2) mm - 3.175
Boundary Dimension (g2) inch - 0.125
Boundary Dimension (H) mm - 19.05
Boundary Dimension (H) inch - 0.75
Boundary Dimension (r) inch - 2.381
Boundary Dimension (r) mm - 0.09375
Minimum Mounting Dimension (f min) mm - 64.691
Minimum Mounting Dimension (f min) inch - 2.546875
Maximum Tightening Torque (N-m) - 2190
Basic Dynamic Load Rating (C) N - 142000
Basic Static Load Rating (C0) N - 317000

Notes :

Descriptions of Prefixes and Suffixes :
-----------------------------------------------------
CRH.....B - Inch Series Cam Followers (Stud Head Hex Hole)
V - Full Complement Type
UU - Sealed Type
