CRH 11 VBUU IKO

IKO

Download Data Sheet

Country Of Origin: JAPAN

Variant

Share this product

Brand - IKO
Category - Inch Series Heavy Duty Cam Followers (Full Complement Type / Stud Head Hex Hole)
Item Number - CRH 11 VBUU IKO
Also Known As - CRH11VBUU
Type - Sealed Type with Cylindrical Outer Ring
Shield Type - CRH 11 VB
Stud Diameter (mm) - 7.938
Stud Diameter (inch) - 0.3125
Weight (kg) - 0.027
Outside Diameter of Outer Diameter (D) mm - 17.462
Outside Diameter of Outer Diameter (D) inch - 0.6875
Width of Outer Ring (C) mm - 11.112
Width of Outer Ring (C) inch - 0.4375
Boundary Dimension (d1) mm - 7.938
Boundary Dimension (d1) inch - 0.3125
G - 5/16 - 24
Boundary Dimension (G1) mm - 7.938
Boundary Dimension (G1) inch - 0.3125
Maximum Boundary Dimension (B) mm - 12.8
Maximum Boundary Dimension (B) inch - 0.5
Boundary Dimension (B2) mm - 19.05
Boundary Dimension (B2) inch - 0.75
Boundary Dimension (C1) mm - 0.794
Boundary Dimension (C1) inch - 0.03125
Boundary Dimension (H) mm - 3.175
Boundary Dimension (H) inch - 0.125
Boundary Dimension (r) inch - 0.397
Boundary Dimension (r) mm - 0.015625
Minimum Mounting Dimension (f min) mm - 11.112
Minimum Mounting Dimension (f min) inch - 0.4375
Maximum Tightening Torque (N-m) - 6.8
Basic Dynamic Load Rating (C) N - 6340
Basic Static Load Rating (C0) N - 8530

Notes :

Descriptions of Prefixes and Suffixes :
-----------------------------------------------------
CRH.....B - Inch Series Cam Followers (Stud Head Hex Hole)
V - Full Complement Type
UU - Sealed Type
