Description
Brand - IKO
Item Number - CRBS 508 IKO
Also Known As - CRBS508
Category - Open and Slim Type Crossed Roller Bearing with Cage
Shaft Diameter (mm) - 50
Bore Diameter (d) mm - 50
Outer Diameter (D) mm - 66
Width (B) mm - 8
Minimum Allowable Single Value of Chamfer Dimension (r) mm - 0.4
Mounting Dimension (da) mm - 54
Mounting Dimension (Da) mm - 61
Basic Dynamic Load Rating (C) N - 4900
Basic Static Load Rating (C0) N - 6170
Weight (kg) - 0.084
Sealed and Slim Type Crossed Roller Bearing with Separator - CRBS 508 A UU
Open and Slim Type Crossed Roller Bearing with Full Complement Type - CRBS 508 V
Sealed and Slim Type Crossed Roller Bearing with Full Complement Type - CRBS 508 V UU
** Images are for representation purposes only
