Description
Brand - IKO
Item Number - CRBC 3010 IKO
Also Known As - CRBC3010
Category - Open and Standard Type Crossed Roller Bearings with Cage
Shaft Diameter (mm) - 30
Bore Diameter (d) mm - 30
Outer Diameter (D) mm - 55
Width (B) mm - 10
Minimum Allowable Single Value of Chamfer Dimension (r) mm - 0.3
Mounting Dimension (da) mm - 34
Mounting Dimension (Da) mm - 44
Basic Dynamic Load Rating (C) N - 3830
Basic Static Load Rating (C0) N - 4130
Weight (kg) - 0.12
Sealed and Standard Type Crossed Roller Bearings with Cage - CRBC 3010 UU
Open and Standard Type Crossed Roller Bearings with Full Complement - CRB 3010
Sealed and Standard Type Crossed Roller Bearings with Full Complement - CRB 3010 UU
** Images are for representation purposes only
