Description
Brand - IKO
Item Number - CRBC 12025 IKO
Also Known As - CRBC12025
Category - Open and Standard Type Crossed Roller Bearings with Cage
Shaft Diameter (mm) - 120
Bore Diameter (d) mm - 120
Outer Diameter (D) mm - 180
Width (B) mm - 25
Minimum Allowable Single Value of Chamfer Dimension (r) mm - 1.5
Mounting Dimension (da) mm - 132
Mounting Dimension (Da) mm - 164
Basic Dynamic Load Rating (C) N - 47700
Basic Static Load Rating (C0) N - 70500
Weight (kg) - 2.62
Sealed and Standard Type Crossed Roller Bearings with Cage - CRBC 12025 UU
Open and Standard Type Crossed Roller Bearings with Full Complement - CRB 12025
Sealed and Standard Type Crossed Roller Bearings with Full Complement - CRB 12025 UU
** Images are for representation purposes only
