Description
Brand - IKO
Item Number - CRB 25025 IKO
Also Known As - CRB25025
Category - Open and Standard Type Crossed Roller Bearings with Full Complement
Shaft Diameter (mm) - 250
Bore Diameter (d) mm - 250
Outer Diameter (D) mm - 310
Width (B) mm - 25
Minimum Allowable Single Value of Chamfer Dimension (r) mm - 2.5
Mounting Dimension (da) mm - 259
Mounting Dimension (Da) mm - 290
Basic Dynamic Load Rating (C) N - 83900
Basic Static Load Rating (C0) N - 183000
Weight (kg) - 4.97
Sealed and Standard Type Crossed Roller Bearings with Full Complement - CRB 25025 UU
Open and Standard Type Crossed Roller Bearings with Cage - CRBC 25025
Sealed and Standard Type Crossed Roller Bearings with Cage - CRBC 25025 UU
** Images are for representation purposes only
