CFKRE 40 VR IKO

Brand - IKO
Category - Eccentric Type Cam Followers Full complement/Double Hex Hole
Item Number - CFKRE 40 VR
Also Known As - CFKRE40VR
Type - Shield Type (with Crowned Outer Ring)
Outside Diameter of Eccentric Collar (mm) - 20
Weight (kg) - 0.022
Outside Diameter of Outer Diameter (D) mm - 269
Width of Outer Ring (C) mm - 40
Boundary Dimension (de) mm - 20
G - M12×1.5
Boundary Dimension (G1) mm - 19
Maximum Boundary Dimension (B) mm - 21.6
Maximum Boundary Dimension (B1) mm - 58.1
Boundary Dimension (B2) mm - 36.5
Boundary Dimension (B3) mm - 16
Boundary Dimension (C1) mm - 0.8
Boundary Dimension (g1) mm - 6
Boundary Dimension (H) mm - 8
Minimum Allowable Value of Chamfer Dimension (rs min) - 1
Eccentricity (ε) mm - 1
Minimum Mounting Dimension (f min) mm - 29
Maximum Tightening Torque (N-m) - 86.2
Basic Dynamic Load Rating (C) N - 25300
Basic Static Load Rating (C0) N - 51300
Maximum Allowable Static Load (N) - 31100
Shield Type (with Cylindrical Outer Ring) - CFKRE 40 V
Sealed Type (with Cylindrical Outer Ring) - CFKRE 40 VUUR
Shield Type (with Cylindrical Outer Ring) - CFKRE 40 VUU

Notes :

Descriptions of Prefixes and Suffixes :
---------------------------------------------------
CFKRE - Eccentric Type Cam Followers(Double Hex Hole )
R - With Crowned Outer Ring
V - Full Complement Type

** Images are for representation purposes only
