Description
Brand - INA
Item Number - BE20-SML INA
Also known as - 204NPPB + E04
Category - Radial Insert Ball Bearings
Inner (d) MM - 20
Outer (D) MM - 55
Width (B) MM - 16
Inner (d) Inch - 0.7874
Outer (D) Inch - 2.1654
Width (B) Inch - 0.6299
Weight (kg) - 0.19
Seal - 2F - Standard Seal for Y-bearings
Lubrication - Standard Lubrication
Special Treatment - No Special Treatment
SML - More Clearance Between Bearings And Housing, This Has No Influence On The Item Without The Suffix SML
** Images are for representation purposes only
