AX 30 47 NADELLA

Brand - NADELLA
Item Number - AX 30 47 NADELLA
Category - Needle Thrust Bearing (Thin Series)

Principal Dimensions & Load Ratings (Metric) :
Shaft Diameter (∅) - 30 mm
Inner Diameter (Dc1) - 30 mm
Outer Diameter (D) - 47 mm
Width (B1) - 2.8 mm
Dimension (Eb) - 32.7 mm
Dimension (Ea) - 42.4 mm
Dynamic Load Rating (C) - 14.5 kN
Static Load Rating (C0) - 57 kN
Speed Rating with Oil - 6500 rpm
Weight - 0.014 kg

Compatible Needle Thrust Plate :
Needle Thrust Plate (Thin Series) - CP 30 47
Inner Ring (d) - 30 mm
Outer Ring (d1) - 46.5 mm
Width (h) - 0.8 mm
Weight - 0.006 kg

Description of Prefix :
AX - Needle thrust bearing

♦ ♦ Images are for representation purposes only
