Description
Brand - NTN
Item Number - 7934CDTBT/GNP4 NTN
Category - Angular Contact Ball Bearing Single Row
Inner (d) MM - 170
Outer (D) MM - 230
Width (B) MM - 112
Weight (kg) - 22.8
Seal - No Seal
Cage Type - M - Brass Cage
Precision - P4 Precision (Higher than P5)
Contact Angle - 15 degrees
Pairing - QFT - X- and Tandem Arrangement, 4
Axial Internal Clearance / Preload - CB - Normal Axial Clearance
Lubrication - Standard Lubrication
