719/850-MPB FAG

Brand - FAG
Item Number - 719/850-MPB FAG
Category - Angular Contact Ball Bearing Single Row
Weight (Kg) - 309
Inner Diameter (d) mm - 850
Outer Diameter (D) mm - 1120
Inner Width (B) mm - 118
Minimum Chamfer Dimension (r) mm - 6
Minimum Chamfer Dimension (r1) mm - 3
Shoulder Diameter Outer Ring (D1) mm - 1022
Distance Between The Apexes Of The Pressure Cones (a) mm - 343
Contact Angle (α°) - 30
Minimum Diameter Of Shaft Shoulder (da) mm - 873
Maximum Diameter Of Housing Shoulder (Da) mm - 1097
Maximum Diameter Of Housing Shoulder (Db) mm - 1107.6
Maximum Fillet Radius Of Shaft (ra) mm - 5
Maximum Fillet Radius Of Housing (ra1) mm - 2.5
Basic Dynamic Load Rating (Cr) kN - 1100
Basic Static Load Rating (C0r) kN - 3150
Calculation Factor (e) - 0.8
Calculation Factor (X) - 0.39
Calculation Factor (Y) - 0.76
Calculation Factor (Y0) - 0.33
Fatigue Limit Load Current (Cur) kN - 47
Limiting Speed (nG) rpm - 800
