719/600-MP FAG

Brand - FAG
Item Number - 719/600-MP FAG
Category - Angular Contact Ball Bearing Single Row
Weight (Kg) - 122
Inner Diameter (d) mm - 600
Outer Diameter (D) mm - 800
Inner Width (B) mm - 90
Minimum Chamfer Dimension (r) mm - 5
Minimum Chamfer Dimension (r1) mm - 2
Shoulder Diameter Outer Ring (D1) mm - 727.5
Shoulder Diameter Inner Ring (d1) mm - 676
Distance Between The Apexes Of The Pressure Cones (a) mm - 247
Contact Angle (α°) - 30
Minimum Diameter Of Shaft Shoulder (da) mm - 618
Maximum Diameter Of Housing Shoulder (Da) mm - 782
Maximum Diameter Of Housing Shoulder (Db) mm - 791.2
Maximum Fillet Radius Of Shaft (ra) mm - 4
Maximum Fillet Radius Of Housing (ra1) mm - 2
Basic Dynamic Load Rating (Cr) kN - 710
Basic Static Load Rating (C0r) kN - 1700
Calculation Factor (e) - 0.8
Calculation Factor (X) - 0.39
Calculation Factor (Y) - 0.76
Calculation Factor (Y0) - 0.33
Fatigue Limit Load Current (Cur) kN - 35.5
Limiting Speed (nG) rpm - 1200
