719/1400-MPB FAG

Brand - FAG
Item Number - 719/1400-MPB FAG
Category - Angular Contact Ball Bearing Single Row
Weight (Kg) - 1230
Inner Diameter (d) mm - 1400
Outer Diameter (D) mm - 1820
Inner Width (B) mm - 185
Minimum Chamfer Dimension (r) mm - 9.5
Minimum Chamfer Dimension (r1) mm - 5
Shoulder Diameter Outer Ring (D1) mm - 1670
Distance Between The Apexes Of The Pressure Cones (a) mm - 557
Contact Angle (α°) - 30
Minimum Diameter Of Shaft Shoulder (da) mm - 1434
Maximum Diameter Of Housing Shoulder (Da) mm - 1786
Maximum Diameter Of Housing Shoulder (Db) mm - 1802
Maximum Fillet Radius Of Shaft (ra) mm - 8
Maximum Fillet Radius Of Housing (ra1) mm - 4
Basic Dynamic Load Rating (Cr) kN - 2040
Basic Static Load Rating (C0r) kN - 7800
Calculation Factor (e) - 0.8
Calculation Factor (X) - 0.39
Calculation Factor (Y) - 0.76
Calculation Factor (Y0) - 0.33
Fatigue Limit Load Current (Cur) kN - 115
Limiting Speed (nG) rpm - 530
