Description
Brand - FAG
Item Number - 689-HLC FAG
Also known as - 554716330000
EAN - 7316577121622
Inner (d) MM - 9
Outer (D) MM - 17
Width (B) MM - 4
Weight (kg) - 0.0038
Bore - C - Cylindrical Bore
Seal - No Seal
Cage Type - S - Steel or Standard Cage
External Modification - No External Modification
Radial Internal Play - Cn Normal Internal Play
Precision - Standard Precision
Lubrication - Standard Lubrication
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
Special Treatment - No Special Treatment
