Description
Brand - SKF
Item Number - 6304ETN9/C3 SKF
Also known as - 6304-E-TVH-C3
EAN - 7316570255331
Inner (d) MM - 20
Outer (D) MM - 52
Width (B) MM - 15
Inner (d) Inch - 0.7874
Outer (D) Inch - 2.0472
Width (B) Inch - 0.5906
Weight (kg) - 0.144
Bore - C - Cylindrical Bore
Seal - No Seal
Cage Type - EP - Poly. Cage/Reinforced Balls
External Modification - No External Modification
Radial Internal Play - C3 Internal Play (Higher than Cn)
Precision - Standard Precision
Lubrication - Standard Lubrication
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
Special Treatment - No Special Treatment
