61992-MB-C3 FAG

Brand - FAG
Item Number - 61992-MB-C3 FAG
Category - Deep Groove Ball Bearing Single Row
Inner Diameter(d) mm - 460
Outer Diameter(D) mm - 620
Weight (Kg) - 64.6
Inner Width(B) mm - 74
Minimum Chamfer Dimension(r) mm - 4
Shoulder diameter outer ring(D1) mm - 569.2
Shoulder diameter inner ring(d1) mm - 512.4
Minimum diameter shaft shoulder(da) mm - 474.6
Maximum diameter of housing shoulder(Da) mm - 605.4
Maximum fillet radius(ra) mm - 3
Basic Dynamic load rating(Cr) kN - 415
Basic Static load rating(C0r) kN - 735
Fatigue limit load current(Cur) kN - 18.1
Calculation factor(f0) - 16.4
Limiting speed (RPM) - 2200
Reference speed (RPM) - 1180
