Description
Brand - FAG
Item Number - 619/900-M FAG
Category - Deep Groove Ball Bearing Single Row
Inner Diameter(d) mm - 900
Outer Diameter(D) mm - 1180
Weight (Kg) - 352
Inner Width(B) mm - 122
Minimum Chamfer Dimension(r) mm - 6
Shoulder diameter outer ring(D1) mm - 1090.5
Shoulder diameter inner ring(d1) mm - 991.5
Minimum diameter shaft shoulder(da) mm - 923
Maximum diameter of housing shoulder(Da) mm - 1157
Maximum fillet radius(ra) mm - 5
Basic Dynamic load rating(Cr) kN - 900
Basic Static load rating(C0r) kN - 2280
Fatigue limit load current(Cur) kN - 50
Calculation factor(f0) - 16.2
Limiting speed (RPM) - 1000
Reference speed (RPM) - 550
