Description
Brand - FAG
Item Number - 619/1900-M FAG
Category - Deep Groove Ball Bearing Single Row
Inner Diameter(d) mm - 1900
Outer Diameter(D) mm - 2430
Weight (Kg) - 2660
Inner Width(B) mm - 230
Minimum Chamfer Dimension(r) mm - 12
Shoulder diameter outer ring(D1) mm - 2265
Shoulder diameter inner ring(d1) mm - 2072
Minimum diameter shaft shoulder(da) mm - 1942
Maximum diameter of housing shoulder(Da) mm - 2388
Maximum fillet radius(ra) mm - 10
Basic Dynamic load rating(Cr) kN - 2400
Basic Static load rating(C0r) kN - 9500
Fatigue limit load current(Cur) kN - 118
Calculation factor(f0) - 16.2
Limiting speed (RPM) - 530
Reference speed (RPM) - 233
