Description
Brand - FAG
Item Number - 6088-M FAG
Category - Deep Groove Ball Bearing Single Row
Inner Diameter(d) mm - 440
Outer Diameter(D) mm - 650
Weight (Kg) - 108
Inner Width(B) mm - 94
Minimum Chamfer Dimension(r) mm - 6
Shoulder diameter outer ring(D1) mm - 583.6
Shoulder diameter inner ring(d1) mm - 507.7
Minimum diameter shaft shoulder(da) mm - 463
Maximum diameter of housing shoulder(Da) mm - 627
Maximum fillet radius(ra) mm - 5
Basic Dynamic load rating(Cr) kN - 550
Basic Static load rating(C0r) kN - 965
Fatigue limit load current(Cur) kN - 25.5
Calculation factor(f0) - 16
Limiting speed (RPM) - 2000
Reference speed (RPM) - 1250
