511/1060-MP-P5 FAG


Country Of Origin: Imported
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - FAG
Item Number - 511/1060-MP-P5 FAG
Category - Axial Deep Groove Ball Bearing
Inner Diameter (d) mm - 1060
Outer Diameter (D) mm - 1250
Height (T) mm - 150
Minimum Mounting Dimension (D1) mm - 1065
Dimension (d1) mm - 1245
Chamfer Dimension (r) mm - 5
Minimum Mounting Dimension (da) mm - 1174
Maximum Mounting Dimension (Da) mm - 1136
Mounting Dimension (ra) mm - 4
Basic Dynamic Load Rating (C) kN - 1530
Basic Static Load Rating (C0) kN - 14600
Limiting Speed for Oil Lubrication (nG oil) 1/min - 280
Axial Run-Out (µm) - 18
Minimum Load Factor (A) - 1100

** Images are for representation purposes only
