Description
Brand - ZEN
Item Number - 3802-B-2RS ZEN
Category - Double Row Thin Section
Inner Diameter (d) mm - 15
Outer Diameter (D) mm - 24
Width (B) mm - 7
Dynamic Load Rating (N) - 2430
Static Load Rating (N) - 1960
Limiting Speed - 16
Weight (kg) - 0.009
Radial Play - 0.003 - 0.018
Outer Ring Material - AISI52100
Inner Ring Material - AISI52100
Ball Material - AISI52100
Notes :
2RS - Rubber Seals
** Images are for representation purposes only
