3219FT1 Link-Belt

Brand - Link-Belt
Item Number - 3219FT1 Link-Belt
Category - Flange Blocks Sleeve Bearing
UPC - 662327437800
Material - 10413093
Model - 3200F
Bore Size (in) - 1 3/16 in
Housing Coating - POWDER COATED
Housing Material - Cast Iron
Housing Style - Flange Block
Housing Type - Flange Block, Four Bolt
Sleeve Material - Porous Sintered Bronze Oil Impregnated
Bearing Brand - LINK-BELT FLEX BLOCK SLEEVE
Bearing Type - SINTERED BRONZE SLEEVE BRG
Bore Length (in) - 1 3/8 in
Distance Between Bolt Holes (in) - 3 1/4 in
Distance from Housing Cast Face to Inner Ring Long Hub Face (in) - 5/32 in
Distance from Mounting Surface to Cap Face (in) - 2 15/64 in
Distance from Mounting Surface to Outer Most Bearing Face (in) - 1 15/32 in
Height - 1.88
Housing Length (in) - 5 19/32 in
Insert - 3219T1
Insert Component Hub Diameter (in) - 1 7/8 in
Length - 4.75
Lubrication Type - SELF LUBRICATING SLEEVE
Maximum Temperature (C) - 93 C
Maximum Temperature (F) - 200 F
Mounting Bolt Size (in) - 7/16 in
Mounting Housing Width (in) - 19/32 in
Mounting Pad Width (in) - 4 1/4 in
Weight (kg) - 1.4061352
